Spezifikation

Rahmen

Genius Carbon HMF Mainframe with Alloy 6061 Swingarm Integrated Suspension Technology Virtual 4 Link kinematic / Adjustable head angle Syncros Cable Integration System BB92 / UDH Interface / 12x148mm with 55mm Chainline

Gabel

FOX 36 Float Performance Elite Air FIT4 3-Modes with low Speed adj. / Kabolt 15x110mm axle 44mm offset / tapered steerer / Reb. Adj. / Lockout 160mm travel

Dämpfer

FOX NUDE 5T EVOL Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend Custom large Air volume / DPS / Reb. Adj. Travel 150-100-Lockout / T185X55mm

Kurbel

SRAM GX Eagle DUB 55mm CL / 32T

Steuersatz

Syncros - Acros Angle adjust & Cable Routing HS System +-0.6° head angle adjustment ZS56/28.6 – ZS56/40 MTB

Lenker

Syncros Hixon iC Carbon Size S & M 15mm rise / Size L & XL 25mm rise back sweep 8° / 780mm Syncros Endurance lock-on grips

Hebel

SRAM GX Eagle AXS Rocker Controller

Bremsen

Shimano XT M8120 4 Piston Disc; Shimano SM-RT76 / 6 Bolt / 203/F and 180/R

Schaltwerk

SRAM GX Eagle AXS 12 Speed Wireless Electronic Shift System

Kette

SRAM CN GX Eagle

Räder

Syncros Revelstoke 1.5 6 Bolt F: 15x110mm, R: 12x148mm 30mm Tubeless ready rim 28H / XD Driver Syncros Axle w/Removable Lever with 6mm Allen, T30 and T25 Tools

Kassette

SRAM XG1275 / 10-52 T

Reifen

Maxxis Dissector / 2.6" / 60TPI Foldable Tubeless Ready / EXO 3C maxx Terra

Sattelstütze

Syncros Duncan Dropper Post 1.5 31.6mm / S size 140mm / M size 160mm / L size 170mm / XL size 200mm

Sattel

Syncros Tofino 1.5 Regular Titanium rails

Gewicht

14,1 Kg

Zusatz

SCOTT TwinLoc 2 Technology Suspension & Dropper Remote 3 Suspension modes; SRAM AXS Powerpack Syncros Fork Fender
